Quick Details

  • Place of Origin: Hubei, China (Mainland)
  • Brand Name: VANJOIN(Fiber Cement Board Wall Panel)
  • Model Number: VJ-WPL228(Fiber Cement Board Wall Panel)
  • Material: Sandwich Panel
  • Use: Carport, Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Shop, Toilet, Villa, Warehouse, Workshop,Plant, Other
  • Product Name: Precast Composite Partition ISO Fiber Cement Board Wall Panel
  • Certificate: ISO9001,ISO14000,,BV certificate,
  • Anti-seismic: Degree 8
  • Sound insulation: 42db
  • Environmental: Without asbestos or sepiolite or any inorganic fibres
  • Best Haging Force: more than 50kgs
  • Installation Team: Provide
  • Efficiency construction: High
  • Area saving: Yes
  • Fireproof: Under 1000 degree centigrade for 240 minutes

Packaging & Delivery

Packaging Details Standard exporting packing (wrapped with plastic thin film,wedge protect and good pallet)
(Fiber Cement Board Wall Panel)
Delivery Time 5-10working days

Precast Composite Partition ISO Fiber Cement Board Wall Panel(Fiber Cement Board)

Product Description

Vanjoin Precast Composite Partition ISO Fiber Cement Board Wall Panel(Fiber Cement Board Wall Panel) is composed of exterior panels and interior core filling, to form a non-load-bearing light-weight composite wall panel. The exterior panels on both sides are 5mm calcium silicate board, and the middle core is filled with polystyrene beads & cement or ceramsite, polystyrene beads & cement.



 > 1. Composition of Precast Composite Partition ISO Fiber Cement Board Wall Panel:

•Core materials: cement, EPS, sand and additives.

•Surface materials: fiber reinforced calcium silicate board or cement calcium silicate board.

Specification

 > 2. Specification of Precast Composite Partition ISO Fiber Cement Board Wall Panel:

•Thickness: 60, 75, 90, 100, 120, 150mm
•Width: 610mm
•Length: 2270mm (custom-made length can be made for volumn order)





Remark: All kinds of Precast Composite Partition ISO Fiber Cement Board Wall Panel(Fiber Cement Board Wall Panel) can be customized by customers' specific requirements,such as density and length of Precast Composite Partition ISO Fiber Cement Board Wall Panel(Fiber Cement Board Wall Panel).



 > 3. Performance of Precast Composite Partition ISO Fiber Cement Board Wall Panel:

Advantages

>4. Feature of Partition Fiber Cement Board Wall Panel(Fiber Cement Board Wall Panel):

1). Fast construction (25m2/day/person)
2). Windproof (65m/s)
3). Sound insulation(46dB)
4). Anti-impact, Anti-seismic (class: 8)
5). Waterproof, Fireproof (4 hours, under 1000 degree centigrade)
6). Light weight, Energy-saving
7). Eco-friendly green material
8). Save area, Easy installation
9). Heat insulation & preservation
10). Strong and durable, 60-70 years life span.

Application

> 5. Applications of Precast Composite Partition Fiber Cement Board Wall Panel(Fiber Panel)

Fiber Cement Board Wall Panel

Installation

   >    6. Installation Guide:

1. Setting the line and carrying the board in position

2. Sawing board

3. Sizing

4. Installation

5. Correcting, fixing

6. Grouting and filling starch

7. Sticking anti-cracking cloth (we can supply )

8. Installing electrical wires and switches

9. Installing doorcase

10. Facing coating and wall papers

11. Facing ceramic tile,decorative sheet

12. Electric apparatus installation



Packaging & Shipping

   >       7. Packing & Shipping:

Standard exporting packing (wrapped with plastic thin film, edge protect and good pallet)

Certifications

  >         8. Certification:



     >   9. Projest case:



Markets

   >         8. Trade Show:

Our Precast Composite Partition ISO Fiber Cement Board Wall Panel(Fiber Cement Board Wall Panel) have been exported to Australia, Nigeria, Iran, Germany, Cyprus, Ireland, Spain, Portugal,etc.

Vanjoin IBS Fair(Orlando, USA) 2017

Vanjoin Thailand Fair, 2017

 >      11. Vanjoin's team:
  >          12. Vanjoin's Professional Service:

  • Energy saving Precast Composite Partition ISO Fiber Cement Board Wall Panel(Fiber Cement Board Wall Panel), prefab house and roof system application professional advice.
  • Manage product and construction technology communication and related documents.
  • International standard installation node diagram design.
  • International standard installation node diagram design.
  • Creative design.
  • Comprehensive technology solutions for the overall system.
  • Other service required by the clients.
  >       13. FAQ:

1 : How many years your company have been in this field?
Ans: More than 10 years of manufacturing Precast Composite Partition ISO Fiber Cement Board Wall Panel(Fiber Cement Board Wall Panel), now we are the TOP 3 in middle of China, and among TOP 3 in China in this field.



2 : Main market of Vanjoin ?
Ans: Main market: Asia, South Amercia, Africa
         South East Asia is our largest market ,Mid East is our second largest market



3 : Exporting details:
Ans: loading & shipping 400 20ft every month



4 : More information of Vanjoin factory ?
Ans: Land area: 30,000m2 Machines: Fully automatic production line
         Productivity: 2,000,000m2 wall panel every year.



5 : How could I get the samples ?
Ans: We send you the free Precast Composite Partition ISO Fiber Cement Board Wall Panel(Fiber Cement Board Wall Panel) samples, brochures & installation cd etc, you pay for the freight charges.

If you get the TNT, DHL, UPS  Fedex account, that is the best.  If not, you can transfer money to our West Union account , then we send you samples by Vanjoin account.
